China AVASPIRE PAEK Manufacturer, Supplier, Factory

High quality AVASPIRE PAEK is offered by China manufacturer Visa Plastics. Buy AVASPIRE PAEK which is of high quality directly with low price. AvaSpire® polyaryletherketone (PAEK) is a family of proprietary polymers that make up a versatile group of tailor-made formulations designed to meet specific application requirements, with some grades offering more attractive economics.

The AvaSpire® PAEK family consists of three polymer chemistries, each with distinct properties.

Figure 1.1 below shows the basic building blocks used to create the various polymers, which offer a variety of performance properties.

Figure 1.1 Basic building blocks

Aryl linkages provide high modulus, thermal stability, and flame retardancy.

Ether linkages provide toughness, ductility and ease of processing.

Ketones provide long-term thermal oxidative resistance.

AV-600 Series Products in the AV-600 series deliver improved ductility and higher flexural and torsional modulus between 150 °C (300 °F) and 190 °C (375 °F) than comparable PEEK grades. They have lower crystallinity than PEEK, which gives them better dimensional stability and lower warpage. The light color of the resin provides good part aesthetics and excellent colorability.

• Higher ductility and toughness than comparable PEEK grades

• Higher stiffness in the temperature range 150 °C to 190 °C (300 °F to 375 °F) than comparable PEEK grades

• Lower crystallinity than PEEK for better dimensional stability and lower warpage

• Light color resin for good part aesthetics

• Excellent colorability AV-700 Series Products in the AvaSpire® AV-700 series fill the cost/ performance gap between ultra-performance crystalline polymers like PEEK and high-performance crystalline polymers like liquid crystal polymers (LCP), polyphenylene sulfide (PPS), and polyphthalamide (PPA).

• Higher modulus than PEEK

• Lower moisture absorption than PPA

• Equivalent or better chemical resistance than PEEK

• Higher thermal capabilities than PPS and PPA

• Better ductility than PPS

• Low friction and excellent wear resistance in dry and lubricated environments

• Up to 30 % cost reduction compared to PEEK
